| Place of Origin: | China |
|---|---|
| Brand Name: | Wuhan ETERN Optoelectronics |
| Certification: | RoHS |
| Model Number: | AAWG-1F48-C14-0505054-MDM |
| Minimum Order Quantity: | 2PCS |
| Price: | Negotiable |
| Packaging Details: | Single item |
| Payment Terms: | T/T |
| Supply Ability: | 50k per month |
| Highlight: | 100GHz Spacing AAWG,Flat Top AAWG,C61 MUX DEMUX |
||
|---|---|---|---|
| Parameters | Unit | Value | |
| Channel Number | 48 | ||
| Channel Spacing | GHz | 100 | |
| Center Wavelength | nm | 1528.773 ~ 1566.314 | |
| Channel Frequency | THz | 191.4 ~196.1 | |
| Reference Passband | nm | ±0.1 | |
| Insertion Loss | dB | ≤5.6 | |
| Insertion Loss Uniformity | dB | ≤1.5 | |
| Passband Ripple | dB | ≤0.5 | |
| Bandwidth | @3dB | GHz | 67 |
| Isolation | Adjacent Channels | dB | ≥25 |
| Non-adjacent Channels | ≥30 | ||
| Total crosstalk | dB | ≥21 | |
| PDL | dB | ≤0.5 | |
| PMD | ps | ≤0.5 | |
| Return Loss | dB | ≥40 | |
| Chromatic Dispersion | ps/nm | ±20 | |
| Operating Temperature | ℃ | -5 to +65 | |
| Storage Temperature | ℃ | -40 to +85 | |
| Directivity | dB | ≥40 | |
| Parameter | Specifications | Unit | |
| Fiber Type | SMF-28e With 900um Loose tube fiber | ||
| Fiber Length | Common Fiber | 500±50 | mm |
| Ribbon Fiber | 500±50 | mm | |
| Fan-out | 500±50 | mm | |
| Optical Adaptors (All port) | LC/UPC | ||
