| Place of Origin: | China |
|---|---|
| Brand Name: | Wuhan ETERN Optoelectronics |
| Certification: | RoHS & Telcordia GR-1221-CORE |
| Model Number: | TFF CWDM 3-port |
| Minimum Order Quantity: | 10PCS |
| Price: | Negotiable |
| Packaging Details: | Individual Package |
| Payment Terms: | T/T |
| Supply Ability: | 50k per month |
| High Light: | 3 Port Thin Film CWDM,100GHz Thin Film CWDM,Low Insertion Loss WDM Device |
||
|---|---|---|---|
▪ Low insertion loss, low PDL
▪ High isolation
▪ Wide operating wavelength
▪ Wide operating temperature
▪ High reliability and stability
▪ Small package size,compact structure,and space saving
▪ WDM system
▪ PON networks
▪ CATV links
Specification
|
Parameter |
|
Units |
Value |
|
|
|
Operating wavelength |
|
nm |
1260~1670nm |
|
|
|
|
|
1540~1560 |
|
|
Transmission band |
|
nm |
1524~1544&1596~1625 |
|
|
|
|
|
customer specified |
|
|
|
|
1260~1360&1480~1500 |
|
|
|
Reflection band |
|
nm |
1260~1500&1550~1581&1640~1670 |
|
|
|
|
|
customer specified |
|
|
Transmission band insertion loss |
|
dB |
≤0.6 |
|
|
Reflection band insertion loss |
|
dB |
≤0.4 |
|
|
Transmission Isolation |
|
dB |
≥30 |
|
|
Reflection Isolation |
|
dB |
≥15 |
|
|
Return loss |
|
dB |
≥50 |
|
|
Directivity |
|
dB |
≥50 |
|
|
Operating Temperature |
|
℃ |
-40 to +85 |
Note: Measured with connectors； IL will be 0.3dB worse and RL will be 5dB lower with connectors.
Mechanical Dimensions (Unit: mm)
Ordering Information
|
FWDM - |
□ |
□□- |
□ |
□□ |
□ |
|
|
|
|
|
|
|
|
|
Spacing |
Channel |
Fiber Type |
Fiber Length |
Connector |
|
FWDM |
1=100GHz |
C21=C21 |
1=250um SM |
00=Adapter |
1=None |
|
2=200GHz |
C22=C22 |
2=900um SM |
05=0.5m |
2=FC/UPC |
|
|
C=CWDM |
21=1221 |
3=2.0mm SM |
10=1.0m |
3=FC/APC |
|
|
X=Special |
31=1331 |
4=3.0mm SM |
15=1.5m |
4=LC/UPC |
|
|
|
...... |
|
20=2.0m |
5=LC/APC |
|
|
|
|
...... |
6=SC/UPC |
||
|
|
|
7=SC/APC |
|||
|
|
|
X=Special |
|||
|
|
|
|
|||
