| Features: | Edge Radiation Mode, Low Coupling Loss, Wide Radiation Lobe | Product Name: | Cable Leaky Feeder |
|---|---|---|---|
| Applications: | Private, Public Security And Signal Wireless System | Quality: | Easy Connection |
| High Light: | 5G radiating coax cable,low coupling loss radiating coax cable,public wireless system cable leaky feeder |
||
Low Coupling Loss Radiating Coax Cable Leaky Feeder For Public Wireless System
Standards Implemented
YD/T 2491-2013 Communication cable - Radiating leaky coaxial cable with foamed polyethylene dielectric and longitudinal wrapped copper outer conductor
GB/T 17737.4-2013 Coaxial communication cables – Part 4: Sectional specification for leaky cables
IEC 61196-4:2015 Coaxial communication cables – Part 4: Sectional specification for radiating cables
IEC 60332-1-2:2015 Tests on electric and optical fibre cables under fire conditions–Part 1-2: Test for vertical flame propagation for a single insulated wire or cable – Procedure for 1 kW pre-mixed flame
IEC 61034-2:2019 Measurement of smoke density of cables burning under defined conditions – Part 2: Test procedure and requirements
IEC 60754-1:2019 Test on gases evolved during combustion of materials from cables – Part 1: Determination of the halogen acid gas content
IEC 60754-2:2019 Test on gases evolved during combustion of materials from cables – Part 2: Determination of acidity (by pH measurement) and conductivity
Product Features
Meet the requirements of wireless communication system, to be used in 2G, 3G, 4G, 5G, Wifi, WLAN and other public wireless communication systems, private, public security and signal wireless system in urban rail transit field;
Edge radiation mode, low coupling loss, wide radiation lobe, large front-back ratio, and wide working band.
