| Place of Origin: | China |
|---|---|
| Brand Name: | Wuhan ETERN Optoelectronics |
| Certification: | SFF-8431,SFF-8432，RoHS |
| Model Number: | FLS25C011S-Lxx |
| Minimum Order Quantity: | 2PCS |
| Price: | Negotiable |
| Packaging Details: | blister box |
| Payment Terms: | T/T |
| Supply Ability: | 100k per month |
| Wavelength: | 850nm | Product Name: | SFP28 |
|---|---|---|---|
| Connector: | LC | Fiber Type: | MM |
| Fiber Length: | 0.5m~30m（Customized） | Warranty: | 1year |
| Application: | Data Centers And Storage Arrays | Operating Temperature: | 0℃~+70℃ |
| High Light: | 850nm Wavelength Optical Transceivers,data center Optical Transceivers,25g sfp28 aoc transceiver |
||
Feature:
1. Compliant to SFP+ MSA
2. Fully RoHS Compliant
3. All metal housing for superior EMI performance
4. Operating data rate up to 25.78Gbps
5. High sensitivity Pin photodiode and TIA
6. AOC duplex connector
7. Hot pluggable 20pin connector
8. Low power consumption<1.2 W
9. 0℃ to 70℃operating wide temperature range
10. Single +3.3V±5% power supply
11. Digital Monitoring SFF-8472 Rev10.2 compliant
Description:
The laser based 25Gigabit SFP28 Transceiver is designed to transmit and receive serial optical data over multimode mode optical fiber. They are compliant with SFF-8431,SFF-8432. The transmitter converts serial CML electrical data into serial optical data. The receiver converts serial optical data into serial CML electrical data.Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472.
| Description: | 25Gb/s SFP28 850nm AOC Transceivers |
| Part NO: | FLS25C011S-Lxx |
| Package: | SFP28 |
| Date Rate (bit/s): | 25G |
| Wavelength: | 850nm |
| cable length: | 0.5m~30m(Customized) |
| TOP°C: | 0℃ ~ 70℃ |
Applications
1. Infiniband Connectivity SDR/DDR/QDR
2. 25Gigabit Ethernet
3. Fiber Channel
4. Data Centers and Storage Arrays
