| Place of Origin: | China |
|---|---|
| Brand Name: | Wuhan ETERN Optoelectronics |
| Certification: | RoHS |
| Model Number: | FLS40C210S |
| Minimum Order Quantity: | 2PCS |
| Price: | Negotiable |
| Packaging Details: | blister box |
| Payment Terms: | T/T |
| Product Name: | QSFP+ | Package: | QSFP+-LC |
|---|---|---|---|
| Date Rate (bit/s): | 41.2G | Wavelength: | 1310nm |
| Reach: | 40KM | Operating Temperature: | 0℃~+70℃ |
| High Light: | hot pluggable 40g optical transceiver,10KM 40g optical transceiver,1310nm qsfp transceiver module |
||
Description:
The FLS40C210S is a 4x10G hot pluggable optical transceiver. It enables the integration of 4 transmitters, 4 receivers and an optical MUX/DeMUX with AAWG into a small form factor package that delivers a 40 Gbps data link in a compact QSFP footprint. The optical connectivity is based on two SMF LC connectors, one for Tx and one for Rx. The Tx and Rx each consist of 4 10Gb/s CWDM channels, whose wavelengths are in the 1300nm range. The QSFP-LR transceiver is designed for applications based on the QSFP MSA, IEEE 802.3ba, and 40GBASE-LR4requirements of up to 10km reach.
Ordering Information:
| Description | Part NO. | Model | Package | Date Rate (bit/s) | Wavelength | Reach | TOP (C) | ||
| 40G |
QSFP LR4 |
FLS40C210S | 40G-LR/10KM | QSFP+-LC | 41.2G | 1310nm | 10KM | 0~70 | |
Feature:
1. Transmission data rate up to 11.2Gbps per channel
2. QSFP+ MSA compliant
3. Compliant to IEEE 802.3ba specification for 40GBASE-LR4 links
4. 4 CWDM un-cooled DFB lasers, using ITU G.694.2 wavelength grid at 1271, 1291, 1311, and 1331nm , with AAWG.
5. High Sensitivity PIN-TIA with AAWG DEMUX.
6. Up to 10km reach over standard single mode fiber
7. Compliant with QDR/DDR Infiniband data rates
8. Hot pluggable electrical interface
9. Power consumption＜2.5W
10. 3.3V power supply
11. RoHS 6 compliant(lead free)
Applications:
1. 40G Ethernet
2. Infiniband QDR and DDR interconnects
3. Client-side 40G Telecom connections
